Catalyst 9200 Cisco
Com o Cisco Catalyst 9200 amplie redes baseadas em intenção em qualquer lugar.
Ajuda via WhatsAppCatalyst 9200 Cisco
Com o Cisco Catalyst 9200 amplie redes baseadas em intenção em qualquer lugar.
Os switches Cisco Catalyst 9200 ampliam o poder das redes baseadas em intenção e a inovação de hardware e software do Catalyst 9000 para um conjunto mais abrangente de implantações.
- 5 de 5
Recursos e benefícios
A segurança da Cisco detecta e impede ameaças
Nosso melhor portfólio de segurança é apoiado por Talos, Trustworthy Systems, criptografia MACSec e segmentação. Obtenha recursos de segurança avançada que protegem a integridade de hardware, software e todos os dados que passam pelo switch.
Reduza o período de inatividade
O Catalyst 9200 Series oferece resiliência, análise e garantia de nível empresarial para manter o funcionamento perfeito da empresa. Fontes de alimentação e ventiladores de FRU, uplinks modulares, patching frio, PoE perpétuo e o maior tempo médio entre falhas (MTBF) do setor fazem com que o Catalyst 9200 Series se destaque em relação a outros switches da categoria.
Simplicidade
Obtenha um provisionamento simples de WebUI ou Cisco DNA Center, combinado com as APIs abertas do Cisco IOS XE e a programabilidade da tecnologia UADP ASIC. O Catalyst 9200 Series oferece operação simples agora com proteção do investimento para futuras inovações.
Compare os modelos Catalyst 9200 Series
Catalyst 9200 de 24 e 48 portas, uplinks fixos de 1 G
C9200L-24T/P-4G, C9200L-48T/P-4G
- Dados e opções de PoE+ completos
- 24 e 48 portas de 1 G
- 4 uplinks fixos SFP de 1 G
- Até 48 portas de PoE+ completo de 30W
- SD-Access, Cisco StackWise, MACSec
- Fontes de alimentação redundantes e ventiladores
- Garantia vitalícia limitada aprimorada (E-LLW)
Catalyst 9200 de 24 e 48 portas, uplinks fixos de 10 G
C9200L-24T/P-4X, C9200L-48T/P-4X
- Dados e opções de PoE+ completos
- 24 e 48 portas de 1 G
- 4 uplinks fixos SFP+ de 10 G
- Até 48 portas de PoE+ completo de 30W
- SD-Access, Cisco StackWise, MACSec
- Fontes de alimentação redundantes e ventiladores
- Garantia vitalícia limitada aprimorada (E-LLW)
Catalyst 9200 de 24 e 48 portas, uplinks modulares
C9200-24T/P, C9200-48T/P
- Dados e opções de PoE+ completos
- 24 e 48 portas de 1 G
- 4 uplinks modulares de 1/10 G, 2 uplinks modulares de 25/40 G
- Até 48 portas de PoE+ completo de 30W
- SD-Access, Cisco StackWise, MACSec
- Fontes de alimentação redundantes FRU e ventiladores
- Garantia vitalícia limitada aprimorada (E-LLW)
Por que atualizar para os switches Catalyst 9200
Núcleo mais rápido, acesso mais rápido
Os switches Catalyst 9200 Series são duas vezes mais rápidos e têm o dobro da capacidade dos switches tradicionais.
Segurança em qualquer lugar
A segurança integrada reduz a superfície de ataque e ajuda a detectar e impedir ameaças.
Gerenciamento centralizado
O SD-Access e WebUI ajudam a resolver as defasagens de qualificação profissional em TI geradas pelas tecnologias de automação, virtualização e nuvem.
Destaques em Cisco Catalyst 9200
Switch Cisco Catalyst 9200 C9200-24T-A
Switch Cisco Catalyst 9200 estende o poder das redes baseadas em intenção . O Catalyst 9200 permitem inovação para um amplo conjunto de implementações.
Switch Cisco Catalyst 9200 24-port PoE+ Switch C9200-24P-A, Network Advantage
Switch Cisco Catalyst 9200 24-port PoE+ Switch C9200-24P-A, Network Advantage
Switch Cisco Catalyst 9200L C9200L-24T-4G-A 24-port Data 4x1G C9200L-24T-4G-A
Switch Cisco Catalyst 9200L C9200L-24T-4G-A 24-port Data 4x1G C9200L-24T-4G-A
Switch Cisco Catalyst 9200 24 portas 8xmGig, 16x1G, PoE+ C9200-24PXG-E
Switch Cisco Catalyst 9200 24-port 8xmGig, 16x1G, PoE+ C9200-24PXG-E, Network Essentials
Switch Cisco Catalyst 9200 48 portas PoE+ C9200-48P-A
Catalyst 9200 48-port PoE+ Switch C9200-48P-A , Network Advantage
Switch Cisco Catalyst 9200L 24 portas 4x10G C9200L-24T-4X-A
Catalyst 9200L 24-port Data 4x10G uplink Switch C9200L-24T-4X-A, Network Advantage
Switch Cisco Catalyst 9200L 48 portas 4x10G C9200L-48T-4X-A
Switch Cisco Catalyst 9200L 48-port Data 4x10G uplink Switch C9200L-48T-4X-A, Network Advantage
Switch Cisco Catalyst 9200L 24 portas 8xmGig, 16x1G, 4x10G, PoE+ C9200L-24PXG-4X-E
Switch Cisco Catalyst 9200L 24-port 8xmGig, 16x1G, 4x10G, PoE+ C9200L-24PXG-4X-E, Network Essentials
Switch Cisco Catalyst 9200L 48 portas 12xmGig, 36x1G, 4x10G PoE+ C9200L-48PXG-4X-A
Switch Cisco Catalyst 9200L 48-port 12xmGig, 36x1G, 4x10G PoE+ C9200L-48PXG-4X-A, Network Advantage
Amplie a rede baseada em intenção em todos os lugares
Cisco ® Switch ® 9200 Series Switches estender o poder das redes intenção baseada e Switch 9000 hardware e software inovação para um amplo conjunto de implementações. Com sua linhagem familiar, os switches Catalyst 9200 Series oferecem simplicidade sem compromisso - ele é seguro, sempre ativado e a TI simplificada.
Como elementos fundamentais da arquitetura de rede digital da Cisco, os switches Catalyst 9200 Series ajudam os clientes a simplificar a complexidade, otimizar a TI e reduzir os custos operacionais, aproveitando a inteligência, a automação e o conhecimento humano que nenhum outro fornecedor pode oferecer independentemente de onde você estiver. jornada de rede baseada.
Os switches Catalyst 9200 Series fornecem recursos de segurança que protegem a integridade do hardware, bem como do software e de todos os dados que fluem através do switch. Ele fornece resiliência que mantém seus negócios funcionando perfeitamente. Combine isso com as APIs abertas do Cisco IOS XE e a capacidade de programação da tecnologia UADP ASIC, os switches Catalyst 9200 Series fornecem o que você precisa agora com proteção de investimento em futuras inovações.
Com capacidade total de PoE +, redundância de energia e de ventilador, largura de banda de empilhamento de até 160 Gbps, uplinks modulares, suporte a recursos da camada 3 e patch a frio, os switches Catalyst 9200 Series são a solução incomparável do setor, com resiliência diferenciada e arquitetura progressiva para filiais econômicas. acesso ao escritório.
Destaques do produto
● Até 48 portas com capacidade total de Power over Ethernet Plus (PoE +)
● Resiliência com unidades substituíveis em campo (FRU) e fonte de alimentação redundante, ventiladores e uplinks modulares
● Opções flexíveis de downlink com dados, PoE + ou mGig
● Eficiência operacional com empilhamento opcional no backplane , suportando largura de banda de empilhamento de até 160 Gbps
● UADP 2.0 Mini com CPU integrada oferece aos clientes escala otimizada com melhor estrutura de custos
● Segurança aprimorada com criptografia AES-128 MACsec , segmentação baseada em políticas e sistemas confiáveis
● Recursos da camada 3 , incluindo OSPF, EIGRP, ISIS, RIP e acesso roteado
● Monitoramento avançado de rede usando o NetFlow flexível total
● Acesso definido por software da Cisco ( acesso SD):
◦ operações e implantação com automação baseada em políticas de borda Simplificado para nuvem gerenciada com Cisco Engine Services Identity (ISE)
◦ Garantia de rede e tempo de resolução aprimorado através do Cisco DNA Center
● Plug and Play (PnP) ativado: uma oferta simples, segura, unificada e integrada para facilitar novos lançamentos ou atualizações de dispositivos de filial ou campus em uma rede existente
● Cisco IOS XE: um sistema operacional comum de licenciamento para a família de produtos corporativos Cisco Catalyst 9000 com suporte para programabilidade orientada por modelo e telemetria de streaming
● ASIC com pipeline programável e recursos de micro-mecanismo, juntamente com alocação configurável e baseada em modelo de encaminhamento das camadas 2 e 3, encaminhamento de listas de controle de acesso (ACLs) e qualidade de serviço (QoS)
Detalhes da plataforma
Modelos e configurações de switch
| Modelos |
Fonte de alimentação FRU |
Fãs de FRU |
Uplinks modulares |
Suporte à largura de banda de empilhamento |
Suporte SD-Access 1 |
| Modelos modulares de uplink (C9200 Enhanced VN SKUs) |
✓ |
✓ |
✓ |
160 Gbps |
Sim (32 redes virtuais) 2 |
| Modelos modulares de uplink (SKUs C9200) |
✓ |
✓ |
✓ |
160 Gbps |
Sim (4 redes virtuais) |
| Modelos de ligação fixa fixos (SKUs C9200L) |
✓ |
✗ |
✗ |
80 Gbps |
Limitado (1 rede virtual) |
1 O Catalyst 9200 autônomo e a pilha podem suportar 25 túneis de acesso (para APs habilitados para malha). Nota: Nas implantações de malha superiores, a migração para a arquitetura sem fio de malha deve considerar esse limite durante o design / implantação
2 Os PIDs do Catalyst 9200-24PB-A, C9200-48PB-A suportam 32 redes virtuais. Esses skus não podem ser empilhados com SKUs C9200 com 4VNs
O Cisco Catalyst 9200 Series é composto de modelos de switch modular (C9200) e fixo (C9200L).
Figura 1.
Switches Cisco Catalyst 9200 Series
Tabela 1. CiscoCconfigurações do switch atalyst série 9200
| Mudar modelo |
Total de downlinks 10/100/1000 ou portas de cobre PoE + |
Configuração de ligação ascendente |
Fonte de alimentação CA primária padrão |
Fãs |
| Modelos modulares de uplink |
||||
| C9200-24T |
Dados de 24 portas |
Opções modulares de ligação ascendente |
PWR-C6-125WAC |
FRU redundante |
| C9200-24P |
24 portas PoE + completo |
Opções modulares de ligação ascendente |
PWR-C6-600WAC |
FRU redundante |
| C9200-24PB |
24 portas PoE + completo |
Opções modulares de ligação ascendente |
PWR-C6-600WAC |
FRU redundante |
| C9200-24PXG |
24 portas PoE + cheias (8 mGig até 10G, 16 portas até 1G) |
Opções modulares de ligação ascendente |
PWR-C6-600WAC |
FRU redundante |
| C9200-48T |
Dados de 48 portas |
Opções modulares de ligação ascendente |
PWR-C6-125WAC |
FRU redundante |
| C9200-48P |
48 portas PoE + completas |
Opções modulares de ligação ascendente |
PWR-C6-1KWAC |
FRU redundante |
| C9200-48PB |
48 portas PoE + completas |
Opções modulares de ligação ascendente |
PWR-C6-1KWAC |
FRU redundante |
| C9200-48PXG |
48 portas PoE + cheias (8 mGig até 10G, 40 portas até 1G) |
Opções modulares de ligação ascendente |
PWR-C6-1KWAC |
FRU redundante |
| Modelos fixos de uplink |
||||
| C9200L-24T-4G |
Dados de 24 portas |
4x uG fixos 1G |
PWR-C5-125WAC |
Redundante fixo |
| C9200L-24P-4G |
24 portas PoE + completo |
4x uG fixos 1G |
PWR-C5-600WAC |
Redundante fixo |
| C9200L-48T-4G |
Dados de 48 portas |
4x uG fixos 1G |
PWR-C5-125WAC |
Redundante fixo |
| C9200L-48P-4G |
48 portas POE + completo |
4x uG fixos 1G |
PWR-C5-1KWAC |
Redundante fixo |
| C9200L-24T-4X |
Dados de 24 portas |
4x uplinks fixos de 1 / 10G |
PWR-C5-125WAC |
Redundante fixo |
| C9200L-24P-4X |
24 portas PoE + completo |
4x uplinks fixos de 1 / 10G |
PWR-C5-600WAC |
Redundante fixo |
| C9200L-48T-4X |
Dados de 48 portas |
4x uplinks fixos de 1 / 10G |
PWR-C5-125WAC |
Redundante fixo |
| C9200L-48P-4X |
48 portas PoE + completas |
4x uplinks fixos de 1 / 10G |
PWR-C5-1KWAC |
Redundante fixo |
| C9200L-24PXG-4X |
24 portas PoE + cheias (8 mGig até 10G, 16 portas até 1G) |
4x uplinks fixos de 1 / 10G |
PWR-C5-600WAC |
Redundante fixo |
| C9200L-48PXG-4X |
48 portas POE + completas (portas de 12 mGig até 10G, 36 portas até 1G) |
4x uplinks fixos de 1 / 10G |
PWR-C5-1KWAC |
Redundante fixo |
| C9200L-24PXG-2Y |
24 portas PoE + cheias (8 mGig até 10G, 16 portas até 1G) |
2x uplinks fixos de 1/10 / 25G |
PWR-C5-600WAC |
Redundante fixo |
| C9200L-48PXG-2Y |
48 portas POE + completas (8 mGig até 10G, 40 portas até 1G) |
2x uplinks fixos de 1/10 / 25G |
PWR-C5-1KWAC |
Redundante fixo |
Módulos de rede
Os Switches Cisco Catalyst 9200 Series são fornecidos com uplinks modulares ou fixos, conforme indicado na Tabela 1. Com SKUs modulares, os módulos de rede substituíveis em campo fornecem proteção ao investimento em infraestrutura, permitindo uma migração sem interrupções de 1G para 10G e além. Quando você compra o switch, pode escolher entre os módulos de rede descritos na Tabela 2.
Figura 2.
Módulos de rede do Cisco Catalyst 9200 Series Switch
Tabela 2. Mod de redenúmeros de peça e descrições
| Módulo de rede |
Descrição |
| C9200-NM-2Y1 |
2 x 25G Network Module |
| C9200-NM-2Q1 |
2 x 40G Network Module |
| C9200-NM-4G |
4x 1G network module |
| C9200-NM-4X |
4x 1G/10G network module |
| C9200-NM-BLANK |
No network module |
1 Supported only on C9200-24PXG, C9200-48PXG
For additional details, please read our FAQ: https://www.cisco.com/c/dam/en/us/products/collateral/switches/catalyst-9000/nb-09-cat-9k-faq-cte-en.pdf.
Platform resiliency
Power supplies
Cisco Catalyst 9200 Series switches support dual field-replaceable power supplies (Figure 3). Each switch ships with one default power supply, and a second identical power supply can be purchased with the initial order or can be added at a later time. The second power supply can provide redundancy or additional power to PoE+ ports as needed.
Intelligent PoE+
● IEEE 802.3at PoE+ (up to 30W per port) is supported on Cisco Catalyst 9200 Series switches to lower the total cost of ownership for deployments that incorporate Cisco IP phones, Cisco Aironet® wireless access points, or other standards-compliant PoE+ end devices. PoE+ removes the need to supply wall power to PoE-enabled devices and eliminates the cost of adding electrical cabling and circuits that would otherwise be necessary in IP phone and WLAN deployments. With Cisco Catalyst 9200 Series switches, PoE+ power allocation is dynamic, and power mapping scales up to a maximum of 1440W of PoE+ power.
● O PoE perpétuo é suportado nos Switches Cisco Catalyst 9200 Series e mantém a energia PoE + durante um recarregamento de Switch. Isso é importante para terminais críticos, como dispositivos médicos, e para terminais da Internet das Coisas (IoT), como luzes alimentadas por PoE, para que não haja interrupção durante a reinicialização do switch.
● Fast PoE: Quando a energia é restaurada em um Switch, o Fast PoE começa a fornecer energia aos terminais sem aguardar o carregamento completo do sistema operacional, acelerando o tempo de inicialização do terminal.
Figura 3.
Fontes de alimentação redundantes duplas Cisco Catalyst 9200 Series Switch
A Tabela 3 lista a disponibilidade de energia PoE + para cada modelo.
Tabela 3. PoE + Poder com fontes de alimentação primária e secundária
| Modelo |
Fonte de alimentação primária padrão |
Energia PoE disponível apenas com fonte de alimentação primária única * |
Fonte de alimentação secundária opcional |
Energia PoE disponível com fonte de alimentação secundária adicional * |
| C9200-24P |
PWR-C6-600WAC |
370W |
PWR-C5-600WAC / PWR-C6-600WAC |
740W |
| C9200-24PB |
PWR-C6-600WAC |
370W |
PWR-C6-600WAC |
740W |
| C9200-24PXG |
PWR-C6-600WAC |
370W |
PWR-C6-600WAC |
740W |
| C9200-48P |
PWR-C6-1KWAC |
740W |
PWR-C5-1KWAC / PWR-C6-1KWAC |
1440W |
| C9200-48PB |
PWR-C6-1KWAC |
740W |
PWR-C6-1KWAC |
1440W |
| C9200-48PXG |
PWR-C6-1KWAC |
740W |
PWR-C6-1KWAC |
1440W |
| C9200L-24P-4G |
PWR-C5-600WAC |
370W |
PWR-C5-600WAC |
740W |
| C9200L-24P-4X |
PWR-C5-600WAC |
370W |
PWR-C5-600WAC |
740W |
| C9200L-48P-4G |
PWR-C5-1KWAC |
740W |
PWR-C5-1KWAC |
1440W |
| C9200L-48P-4X |
PWR-C5-1KWAC |
740W |
PWR-C5-1KWAC |
1440W |
| C9200L-24PXG-4X |
PWR-C5-600WAC |
370W |
PWR-C5-600WAC |
740W |
| C9200L-48PXG-4X |
PWR-C5-1KWAC |
740W |
PWR-C5-1KWAC |
1440W |
| C9200L-24PXG-2Y |
PWR-C5-600WAC |
370W |
PWR-C5-600WAC |
740W |
| C9200L-48PXG-2Y |
PWR-C5-1KWAC |
740W |
PWR-C5-1KWAC |
1440W |
* Limitado pelo número da porta e classificação de porta (por exemplo, 24 portas PoE + 30W = 720W)
Empilhamento
Os modelos de switch Cisco Catalyst 9200 Series foram projetados para empilhar switches como um único switch virtual, permitindo que os clientes tenham um único plano de gerenciamento e controle para até 384 portas de acesso.
A Tabela 4 lista as opções de empilhamento suportadas.
Tabela 4. Stac suportadoopções de rei
| Modelo |
Suporte de empilhamento |
Suporte à largura de banda de empilhamento |
Empilhamento de hardware |
Número de membros |
Membros da pilha suportados |
| Modelos modulares (SKUs C9200) |
StackWise ® -160 |
160 Gbps |
C9200-KIT DE EMPILHADEIRA |
8 |
Outros modelos C9200 com o mesmo nível de licença |
| Modelos fixos (SKUs C9200L) |
StackWise-80 |
80 Gbps |
C9200L-STACK-KIT |
8 |
Outros modelos C9200L com o mesmo nível de licença |
O empilhamento misto não é suportado . Você não pode empilhar (SKUs C9200L) fixos com modelos modulares (SKUs C9200) ou outros Switches Catalyst, por exemplo, Cisco Catalyst 2960-X e 2960-XR Series.
Os kits opcionais StackWise-160 e StackWise-80 consistem em dois adaptadores e um cabo de empilhamento. O cabo de empilhamento padrão é de 0,5 m, mas também estão disponíveis opções de 1 e 3 m. A Tabela 5 lista os acessórios de empilhamento.
Tabela 5. Acesso de empilhamentoories
| Modelo |
Descrição |
| C9200-KIT DE EMPILHADEIRA |
Kit de pilha apenas para SKUs C9200: Dois adaptadores de pilha de dados e um cabo de pilha de dados |
| C9200L-STACK-KIT |
Kit de pilha apenas para SKUs C9200L: dois adaptadores de pilha de dados e um cabo de pilha de dados |
| STACK-T4-50CM |
Cabo de 50 cm da pilha de dados (cabo padrão com o Stack Kit) |
| STACK-T4-1M |
Pilha de dados 1 m de cabo |
| PILHA T4-3M |
Pilha de dados 3 m de cabo |
Figura 4.
Unidades empilhadas do Cisco Catalyst 9200 Series Switch
Ventilador
Os switches Cisco Catalyst 9200 Series também vêm com dois ventiladores e oferecem suporte a redundância. Os switches Cisco Catalyst 9200 Series suportam redundância com ventiladores duplos. Nos SKUs C9200, as unidades de ventilador são substituíveis em campo, enquanto nos SKUs C9200L fixos, as unidades de ventilador são fixas. A Tabela 5 lista o número de peça do módulo do ventilador.
Tabela 6. Modificador de ventiladorules
| Modelo |
Descrição |
| C9200-FAN = |
Módulo do ventilador |
Desempenho e escalabilidade
A Tabela 7 lista as métricas de desempenho e escalabilidade para os switches Cisco Catalyst 9200 Series. A Tabela 8 lista as especificações de largura de banda.
Tabela 7. Execuçãoespecificações de desempenho
| Descrição |
C9200-24T, C9200-24P, C9200-48T, C9200-48P, C9200-24PB, C9200-48PB, C9200-24PXG, C9200-48PXG |
C9200L-24T-4G, C9200L-24P-4G, C9200L-48T-4G, C9200L-48P-4G, C9200L-24T-4X, C9200L-24P-4X C9200L-48T-4X, C9200L-48P-4X, C9200L-24PXG -4X, C9200L-48PXG-4X, C9200L-24PXG-2Y, C9200L-24PXG-4X |
| Redes Virtuais |
4 para C9200-24T, C9200-24P, C9200-48T, C9200-48P, C9200-24PXG, C9200-48PXG 32 para C9200-24PB, C9200-48PB |
1 1 |
| Empilhamento de largura de banda |
160 Gbps |
80 Gbps |
| Número total de endereços MAC |
32.000 |
16.000 |
| Número total de rotas IPv4 (ARP mais rotas aprendidas) |
14.000 (10.000 rotas diretas e 4.000 rotas indiretas) |
11.000 (8.000 rotas diretas e 3.000 rotas indiretas) |
| Entradas de roteamento IPv4 |
4,000 |
3,000 |
| IPv6 routing entries |
2,000 |
1,500 |
| Multicast routing scale |
1,000 |
1,000 |
| QoS scale entries |
1,000 |
1,000 |
| ACL scale entries |
1,600 |
1,500 |
| Packet buffer per SKU |
6 MB buffers for 24- or 48-port Gigabit Ethernet models , 12MB buffers for 24 or 48 port multigigabit models |
6 MB buffers for 24- or 48-port Gigabit Ethernet models, 12 MB buffers for 24 or 48 port multigigabit models |
| Flexible NetFlow (FNF) entries |
16,000 flows on 24- and 48-port Gigabit Ethernet models |
16,000 flows on 24- and 48-port Gigabit Ethernet models, 32,000 flows on 24 or 48 port multigigabit models |
| DRAM |
4 GB |
2 GB |
| Flash |
4 GB |
4 GB |
| VLAN IDs |
4096 |
4096 |
| Total Switched Virtual Interfaces (SVIs) |
1000 |
512 |
| Jumbo frames |
9198 bytes |
9198 bytes |
| Wireless bandwidth per switch |
Up to 48 Gbps on 24-port and 48-port Gigabit Ethernet model |
N/A |
| IP SGT binding scale |
8K |
10K |
| Number of IPv4 bindings |
8K |
10K |
| Number of SGT/DGT policies |
2K |
2K |
| Number of SXP Sessions |
200 |
200 |
Table 8. Bandwidth specifications
| Description |
Switching capacity |
Switch capacity with Stacking |
Forwarding rate |
Forwarding rate with Stacking |
| C9200-24T |
128 Gbps |
288 Gbps |
95.23 Mpps |
214 Mpps |
| C9200-24P |
128 Gbps |
288 Gbps |
95.23 Mpps |
214 Mpps |
| C9200-24PB |
128 Gbps |
288 Gbps |
95.23 Mpps |
214 Mpps |
| C9200-24PXG |
352 Gbps |
532 Gbps |
261.90 Mpps |
395 Mpps |
| C9200-48T |
176 Gbps |
336 Gbps |
130.95 Mpps |
250 Mpps |
| C9200-48P |
176 Gbps |
336 Gbps |
130.95 Mpps |
250 Mpps |
| C9200-48PB |
176 Gbps |
336 Gbps |
130.95 Mpps |
250 Mpps |
| C9200-48PXG |
400 Gbps |
580 Gbps |
297.61 Mpps |
431 Mpps |
| C9200L-24T-4G |
56 Gbps |
136 Gbps |
41.66 Mpps |
101 Mpps |
| C9200L-24P-4G |
56 Gbps |
136 Gbps |
41.66 Mpps |
101 Mpps |
| C9200L-48T-4G |
104 Gbps |
184 Gbps |
77.38 Mpps |
137 Mpps |
| C9200L-48P-4G |
104 Gbps |
184 Gbps |
77.38 Mpps |
137 Mpps |
| C9200L-24T-4X |
128 Gbps |
208 Gbps |
95.23 Mpps |
155 Mpps |
| C9200L-24P-4X |
128 Gbps |
208 Gbps |
95.23 Mpps |
155 Mpps |
| C9200L-48T-4X |
176 Gbps |
256 Gbps |
130.95 Mpps |
190 Mpps |
| C9200L-48P-4X |
176 Gbps |
256 Gbps |
130.95 Mpps |
190 Mpps |
| C9200L-24PXG-4X |
272 Gbps |
352 Gbps |
214.28 Mpps |
262 Mpps |
| C9200L-24PXG-2Y |
292 Gbps |
372 Gbps |
229.16 Mpps |
277 Mpps |
| C9200L-48PXG-4X |
392 Gbps |
472 Gbps |
291.66 Mpps |
351 Mpps |
| C9200L-48PXG-2Y |
340 Gbps |
420 Gbps |
252.97 Mpps |
313 Mpps |
*Measured with 64 byte packets
Platform software benefits
Cisco IOS XE
Cisco IOS XE Software opens a completely new paradigm in network configuration, operation, and monitoring through network automation. Cisco’s automation solution is open, standards-based, and extensible across the entire lifecycle of a network device. The various automation mechanisms are outlined below.
● Automated device provisioning is the ability to automate the process of upgrading software images and installing configuration files on Cisco Catalyst switches when they are being deployed in the network for the first time. Cisco provides turnkey solutions such as Plug and Play and Preboot Execution Environment (PXE) that enable an effortless and automated deployment.
● API-driven configuration is available with modern network switches such as Cisco Catalyst 9200 Series switches. It supports a wide range of automation features and provides robust open APIs over NETCONF and RESTCONF using YANG data models for external tools, both off the shelf and custom built, to automatically provision network resources.
● Granular visibility enables model-driven telemetry to stream data from a switch to a destination. The data to be streamed is identified through subscription to a data set in a YANG model. The subscribed data set is streamed to the destination at specified intervals. Additionally, Cisco IOS XE enables the push model. It provides near-real-time monitoring of the network, leading to quick detection and rectification of failures.
● Seamless software upgrades and patching supports OS resilience. On Cisco Catalyst 9200 Series switches Cisco IOS XE supports cold patching with reboot, which provides fixes for critical bugs and security vulnerabilities between regular maintenance releases. This support lets you add patches without having to wait for the next maintenance release. Cold patching requires the switch to be rebooted after patching to allow the changes to take effect.
● Trustworthy solutions built with Cisco Trust Anchor Technologies provide a highly secure foundation for Cisco products. With Cisco Catalyst 9200 Series switches, these technologies enable hardware and software authenticity assurance for supply chain trust and strong mitigation against man-in-the-middle attacks that compromise software and firmware. Trust Anchor capabilities include image signing, Secure Boot, and Cisco Trust Anchor module.
● High availability: Cisco Catalyst 9200 Series switches support high-availability features, including the following:
◦ Cross-stack EtherChannel provides the ability to configure Cisco EtherChannel technology across different members of the stack for high resiliency.
◦ IEEE 802.1s Multiple Spanning Tree Protocol (MSTP) provides rapid spanning tree convergence independent of spanning tree timers and also offers the benefit of Layer 2 load balancing and distributed processing.
◦ Per-VLAN Rapid Spanning Tree (PVRST+) allows rapid spanning tree (IEEE 802.1w) reconvergence on a per-VLAN spanning tree basis, providing simpler configuration than MSTP. In both MSTP and PVRST+ modes, stacked units behave as a single spanning tree node.
◦ Switch-port auto-recovery (“err-disable” recovery) automatically attempts to reactivate a link that is disabled because of a network error.
◦ The Catalyst 9200 Series platform delivers the best SSO resiliency architecture in a stackable solution with sub-50-ms failover.
The Foundation of Software-Defined Access
Secure Segmentation with SD-Access
The enterprise network lies at the heart of digital transformation. A network that is open, programmable, integrated, and secure maximizes business agility, allowing new business opportunities to be pursued and captured.
Cisco DNA with SD-Access is the network fabric that powers business. It is an open and extensible software-driven architecture that accelerates and simplifies your enterprise network operations. The programmable architecture frees your IT staff from time-consuming, repetitive network configuration tasks so they can focus instead on innovation that positively transforms your business. SD-Access enables policy-based automation from edge to cloud with foundational capabilities. These include:
● Simplified device deployment
● Unified management of wired and wireless networks
● Network virtualization and segmentation
● Group-based policies
● Context-based analytics
● SD-Access: Cisco Catalyst 9200 Series switches are the entry-level devices for SD-Access, Cisco’s lead enterprise architecture, with policy-based automation from edge to cloud.
◦ Simplified segmentation and micro-segmentation, with predictable performance and scalability
◦ Automation through Cisco DNA Center
◦ Policy handled through the Cisco Identity Services Engine (ISE)
◦ Faster launch of new business services and significantly improved issue resolution time
● Assurance
◦ Full network visibility and monitoring
◦ End-to-end Quality of Experience (QoE)
◦ Fast issue resolution and network remediation
● Plug and Play (PnP) enabled: A simple, secure, unified, and integrated offering to ease new branch or campus device rollouts or updates to an existing network
● Umbrella Integration:
Small to midsize networks reliant on managed service providers can now host Cisco Umbrella agent directly on their Catalyst 9200 series switches. This allows the business to easily customize their DNS filtering policies to prevent BYOD or IoT guest or corporate users from accessing malicious or inappropriate websites, without having to rely on the MSP to push the policies out. It also lets them optimize use of bandwidth by allowing direct cloud access for trusted apps. Requires DNA-Advantage License and Umbrella License per device.
Full Flexible NetFlow
● Full Flexible NetFlow (FNF): Cisco IOS FNF is the next generation in flow visibility technology. It enables optimization of the network infrastructure, reduces operation costs, and improves capacity planning and security incident detection with increased flexibility and scalability. Catalyst 9200 Series switches are capable of up to 16,000 flow entries on 48-port and 24 port models.
QoS
● Superior QoS: Cisco Catalyst 9200 Series switches offer Gigabit Ethernet speeds with intelligent services that keep traffic flowing smoothly, even at 10 times the normal network speed. Industry-leading mechanisms for cross-stack marking, classification, and scheduling deliver superior performance for data, voice, and video traffic at wire speed. Superior QoS includes granular wireless bandwidth management and fair sharing, 802.1p Class of Service (CoS) and Differentiated Services Code Point (DSCP) field classification, Shaped Round Robin (SRR) scheduling, Committed Information Rate (CIR), and eight egress queues per port.
Smart operation
● WebUI:
WebUI is an embedded GUI-based device-management tool that provides the ability to provision the device, to simplify device deployment and manageability, and to enhance the user experience. It comes with the default image, so there is no need to enable anything or install any license on the device. You can use WebUI to build configurations, and to monitor and troubleshoot the device without having CLI expertise.
● RFID tags:
Cisco Catalyst 9200 Series switches have an embedded RFID tag that facilitates easy asset and inventory management using commercial RFID readers.
● Blue beacon:
Cisco Catalyst 9200 Series switches support both front and back blue beacon LEDs for easy identification of the switch being accessed.
● Efficient switch operation*:
Cisco Catalyst 9200 Series switches provide optimum power saving with Energy Efficient Ethernet (EEE) on the RJ-45 ports and low-power operations for industry best-in-class power management and power consumption capabilities. The ports support reduced power modes so that ports not in use can move into a lower power utilization state. Other efficient switch operation features are as follows:
◦ Per-port power consumption command allows customers to specify a maximum power setting on an individual port.
◦ Per-port PoE power sensing measures actual power being drawn, enabling more intelligent control of powered devices. The PoE MIB provides proactive visibility into power usage and allows you to set different power-level thresholds.
● Bluetooth ready:
Cisco Catalyst 9200 Series switches have hardware support to connect a Bluetooth dongle to your switch, enabling you to use this wireless interface as an IP management port interface. The port can be used for configuration and troubleshooting using WebUI or the Command-Line Interface (CLI), and to transfer images and configurations.
High-performance ip routing
The Cisco Express Forwarding hardware routing architecture delivers extremely high-performance IP routing in Cisco Catalyst 9200 Series switches, based on:
● IP unicast routing protocols (including static, Routing Information Protocol Version 1 [RIPv1], RIPv2, RIPng, and Open Shortest Path First [OSPF], Routed Access) are supported for small network routing applications with the Network Essentials stack. Equal-cost routing facilitates Layer 3 load balancing and redundancy across the stack.
● Advanced IP unicast routing protocols (including Full [OSPF], Enhanced Interior Gateway Routing Protocol [EIGRP], and Intermediate System-to-Intermediate System Version 4 [IS-ISv4]) are supported for load balancing and for constructing scalable LANs. IPv6 routing (using OSPFv3 and EIGRPv6) is supported in hardware for maximum performance.
● Protocol-Independent Multicast (PIM) for IP multicast routing is supported, including PIM sparse mode (PIM SM), and Source-Specific Multicast (SSM).
● IPv6 addressing is supported on interfaces with appropriate show commands for monitoring and troubleshooting.
Packaging: Network and Cisco DNA licensing
The Cisco Catalyst 9000 family of switches introduces a new and simplified licensing package in the form of base and add-on licenses.
● The perpetual licensing package includes the Network Essentials and Network Advantage licensing options that are tied to the hardware. Between them, the base licensing packages cover switching fundamentals, management automation, troubleshooting, and advanced switching features. These Network licenses are perpetual.
● The subscription licensing package includes the Cisco DNA Essentials and Cisco DNA Advantage options. In addition to on-box capabilities, the features available with this package provide Cisco innovations on the switch, as well as on Cisco DNA Center. The Cisco DNA subscription licenses are mandatory at the time of configuration. With Cisco DNA software licenses, customers receive embedded SWSS – which covers 24x7x365 Cisco Technical Assistance Center (TAC) support, software release updates, advanced support analytics, and designated service management. This is valid only for the Cisco DNA software subscription stacks (Cisco DNA Essentials, Advantage, and Premier).
Note: For full hardware support, including the perpetual network stack customers will require Smart Net Total Care for 24x7x365 Cisco Technical Assistance Center (TAC) support, proactive security and product alerts, and product lifecycle management. An additional option for hardware support is Solution Support for your multivendor Cisco solution environment
License consumption is easily determined by the package itself. While perpetual licenses are always permanent and without an expiration date, subscription licenses have to be purchased for a 3-, 5-, or 7-year term (and hence are also known as term-based licenses). Table 12 shows the combinations of perpetual and subscription licenses that must be purchased.
Supported licensing combinations
Table 9. Licensing combinations
|
|
Cisco DNA Premier |
||
| No |
|||
| Yes |
No* |
* At the time of license renewal, the Cisco DNA Essentials license can be purchased to be used with Network Advantage.
Cisco DNA Premier subscription
Cisco DNA Premier subscriptions offer a flexible way to buy software for the access, WAN, and data center domains. At each stage in the product lifecycle, Cisco DNA Premier subscriptions help make buying, managing, and upgrading your network and infrastructure software easier. Cisco DNA Premier subscriptions provide:
● Flexible licensing models to smoothly distribute customers’ software spending over time
● Investment protection for software purchases through software services–enabled license portability
● Lower cost of entry with the new Cisco DNA Premier Subscription for Switching model
For ordering information for Cisco DNA Premier Software for Cisco Catalyst 9200 Series switches, go to: https://www.cisco.com/c/en/us/products/collateral/software/one-subscription-switching/nb-06-dna-sw-sub-access-sw-ctp-en.html.
Cisco Catalyst 9200 Series switches run on Cisco IOS XE Release 16.9.2 or later. This software release includes all the features listed earlier in the Platform Software Benefits section.
Managing licenses with Smart Accounts: Creating Smart Accounts by using the Cisco Smart Software Manager (Cisco SSM) enables you to order devices and licensing packages and also manage your software licenses from a centralized website. You can set up Cisco SSM to receive daily email alerts and to be notified of expiring add-on licenses that you want to renew.
You must order an add-on license in order to purchase a switch. When the license term expires, you can either renew the add-on license to continue using it or deactivate the add-on license and then reload the switch to continue operating with the base license capabilities.
Both the base and add-on licenses are also available for a 90-day evaluation period. An evaluation license is activated temporarily, without purchase. An expired evaluation license cannot be reactivated after reload.
Note: It is not required to deploy Cisco DNA Center, just to use one of the above packages.
Tables 10 shows the features included in the Network Essentials and Advantage packages.
Table 11 shows the features included in the Cisco DNA Essentials and Advantage packages.
Network licensing
Table 10. Network essentials and advantage package features
| Features on Cisco Catalyst uplink switches |
Network Essentials |
Network Advantage |
| Switch fundamentals Layer 2, Routed Access (RIP, EIGRP Stub, OSPF - 1000 routes), PBR, PIM Stub Multicast (1000 routes), PVLAN, VRRP, PBR, CDP, QoS, FHS, 802.1X, MACsec-128, CoPP, SXP, IP SLA Responder,SSO |
✓ |
✓ |
| Advanced switch capabilities and scale EIGRP, HSRP, IS-IS, BSR, MSDP, IP SLA, OSPF |
✗ |
✓ |
| Network segmentation VRF, VXLAN, LISP, SGT |
✗ |
✓ |
| Automation NETCONF, RESTCONF, YANG, PnP Agent, PnP |
✓ |
✓ |
| Telemetry and visibility Model-driven telemetry, sampled NetFlow, SPAN, RSPAN |
✓ |
✓ |
| Security MACsec-128 |
✓ |
✓ |
Cisco DNA licensing
Table 11. Cisco DNA Essentials, Advantage, and Premier Package Features
| Features |
Cisco DNA Essentials |
Cisco DNA Advantage |
Cisco DNA Premier |
| Switch features |
|||
| Advanced telemetry and visibility |
✓ |
✓ |
✓ |
| Optimized telemetry and visibility |
✗ |
✓ |
✓ |
| Cisco DNA Center features |
|||
| Day-0 network bring-up automation |
✓ |
✓ |
✓ |
| Element management |
✓ |
✓ |
✓ |
| Element management |
✗ |
✓ |
✓ |
| Basic Assurance |
✓ |
✓ |
✓ |
| SD-Access |
✗ |
✓ |
✓ |
| Network assurance and analytics |
✗ |
✓ |
✓ |
| Other Software included (can be purchased separately) |
|
|
|
| ISE Base |
✗ |
✗ |
✓ |
| ISE Plus |
✗ |
✗ |
✓ |
| StealthWatch |
✗ |
✗ |
✓ |
Dimensions, Eight, Acoustic, Mean time between failures
Table 12 shows the dimensions, weights, acoustic, and mean time between failures of all models of Cisco Catalyst 9200 Series switches.
Table 12. Model Dimensions, Weight, and Mean time between failures metrics
| Platform Physical Specifications |
||||
|
|
Chassis Dimensions |
Chassis + FEP + Fan Dimensions (HxWxD) |
||
| Model |
Inches |
Centimeters |
Inches |
Centimeters |
| C9200-24T |
1.73 x 17.5 x 13.8 |
4.4 x 44.5 x 35.0 |
1.73 x 17.5 x 15.4 |
4.4 x 44.5 x 39.1 |
| C9200-24P |
1.73 x 17.5 x 13.8 |
4.4 x 44.5 x 35.0 |
1.73 x 17.5 x 15.4 |
4.4 x 44.5 x 39.1 |
| C9200-24PB |
1.73 x 17.5 x 13.8 |
4.4 x 44.5 x 35.0 |
1.73 x 17.5 x 15.4 |
4.4 x 44.5 x 39.1 |
| C9200-24PXG |
1.73 x 17.5 x 13.8 |
4.4 x 44.5 x 35.0 |
1.73 x 17.5 x 15.4 |
4.4 x 44.5 x 39.1 |
| C9200-48T |
1.73 x 17.5 x 13.8 |
4.4 x 44.5 x 35.0 |
1.73 x 17.5 x 15.4 |
4.4 x 44.5 x 39.1 |
| C9200-48P |
1.73 x 17.5 x 13.8 |
4.4 x 44.5 x 35.0 |
1.73 x 17.5 x 15.4 |
4.4 x 44.5 x 39.1 |
| C9200-48PB |
1.73 x 17.5 x 13.8 |
4.4 x 44.5 x 35.0 |
1.73 x 17.5 x 15.4 |
4.4 x 44.5 x 39.1 |
| C9200-48PXG |
1.73 x 17.5 x 13.8 |
4.4 x 44.5 x 35.0 |
1.73 x 17.5 x 15.4 |
4.4 x 44.5 x 39.1 |
| C9200L-24T-4G |
1.73 x 17.5 x 11.3 |
4.4 x 44.5 x 28.8 |
1.73 x 17.5 x 12.9 |
4.4 x 44.5 x 32.9 |
| C9200L-24P-4G |
1.73 x 17.5 x 11.3 |
4.4 x 44.5 x 28.8 |
1.73 x 17.5 x 12.9 |
4.4 x 44.5 x 32.9 |
| C9200L-48T-4G |
1.73 x 17.5 x 11.3 |
4.4 x 44.5 x 28.8 |
1.73 x 17.5 x 12.9 |
4.4 x 44.5 x 32.9 |
| C9200L-48P-4G |
1.73 x 17.5 x 11.3 |
4.4 x 44.5 x 28.8 |
1.73 x 17.5 x 12.9 |
4.4 x 44.5 x 32.9 |
| C9200L-24T-4X |
1.73 x 17.5 x 11.3 |
4.4 x 44.5 x 28.8 |
1.73 x 17.5 x 12.9 |
4.4 x 44.5 x 32.9 |
| C9200L-24P-4X |
1.73 x 17.5 x 11.3 |
4.4 x 44.5 x 28.8 |
1.73 x 17.5 x 12.9 |
4.4 x 44.5 x 32.9 |
| C9200L-48T-4X |
1.73 x 17.5 x 11.3 |
4.4 x 44.5 x 28.8 |
1.73 x 17.5 x 12.9 |
4.4 x 44.5 x 32.9 |
| C9200L-48P-4X |
1.73 x 17.5 x 11.3 |
4.4 x 44.5 x 28.8 |
1.73 x 17.5 x 12.9 |
4.4 x 44.5 x 32.9 |
| C9200L-24PXG-4X |
1.73 x 17.5 x 13.8 |
4.4 x 44.5 x 35.0 |
1.73 x 17.5 x 15.4 |
4.4 x 44.5 x 39.1 |
| C9200L-24PXG-2Y |
1.73 x 17.5 x 13.8 |
4.4 x 44.5 x 35.0 |
1.73 x 17.5 x 15.4 |
4.4 x 44.5 x 39.1 |
| C9200L-48PXG-4X |
1.73 x 17.5 x 13.8 |
4.4 x 44.5 x 35.0 |
1.73 x 17.5 x 15.4 |
4.4 x 44.5 x 39.1 |
| C9200L-48PXG-2Y |
1.73 x 17.5 x 13.8 |
4.4 x 44.5 x 35.0 |
1.73 x 17.5 x 15.4 |
4.4 x 44.5 x 39.1 |
| Model |
Pounds |
Kilograms |
| C9200-24T |
11.02 |
5.0 |
| C9200-24P |
12.12 |
5.5 |
| C9200-24PB |
12.12 |
5.0 |
| C9200-24PXG |
11.33 |
5.1 |
| C9200-48T |
11.02 |
5.0 |
| C9200-48P |
12.12 |
5.5 |
| C9200-48PB |
12.12 |
5.5 |
| C9200-48PXG |
11.98 |
5.45 |
| C9200L-24T-4G |
9.59 |
4.35 |
| C9200L-24P-4G |
10.38 |
4.71 |
| C9200L-48T-4G |
9.97 |
4.53 |
| C9200L-48P-4G |
10.58 |
4.80 |
| C9200L-24T-4X |
9.59 |
4.35 |
| C9200L-24P-4X |
10.38 |
4.71 |
| C9200L-48T-4X |
9.97 |
4.53 |
| C9200L-48P-4X |
10.58 |
4.80 |
| C9200L-24PXG-4X |
12 |
5.44 |
| C9200L-24PXG-2Y |
12 |
5.44 |
| C9200L-48PXG-4X |
12.6 |
5.71 |
| C9200L-48PXG-2Y |
12.6 |
5.71 |
| Mean time between failures (hours) |
|
| C9200-24T |
587,800 |
| C9200-24P |
422,310 |
| C9200-24PB |
434,220 |
| C9200-24PXG |
353,960 |
| C9200-48T |
571,440 |
| C9200-48P |
375,570 |
| C9200-48PB |
384,980 |
| C9200-48PXG |
320,440 |
| C9200L-24T-4G |
531,030 |
| C9200L-24P-4G |
392,210 |
| C9200L-48T-4G |
508,700 |
| C9200L-48P-4G |
347,760 |
| C9200L-24T-4X |
525,990 |
| C9200L-24P-4X |
390,310 |
| C9200L-48T-4X |
503,400 |
| C9200L-48P-4X |
346,270 |
| C9200L-24PXG-4X |
379,410 |
| C9200L-24PXG-2Y |
374,730 |
| C9200L-48PXG-4X |
337,360 |
| C9200L-48PXG-2Y |
337,260 |
| PWR-C5-125WAC |
3,332,120 |
| PWR-C5-600WAC |
1,600,060 |
| PWR-C5-1KWAC |
1,600,060 |
| PWR-C6-125WAC |
3,332,120 |
| PWR-C6-600WAC |
1,600,060 |
| PWR-C6-1KWAC |
1,600,060 |
| Environmental ranges |
|
| Acoustic noise Measured per ISO 7779 and declared per ISO 9296 Bystander positions operating to an ambient temperature of 25°C |
With AC power supply (with 24 PoE+ ports loaded):
● LpA: 42dB typical, 45 dB max
● LwA: 5.3B typical, 5.6B max
Typical: Noise emission for a typical configuration Maximum: Statistical maximum to account for variation in production |
Connectors
Table 13 shows the supported connectors for Cisco Catalyst 9200 Series switches.
| Connectors and cabling |
● 1000BASE-T ports: RJ-45 connectors, 4-pair Cat 5E UTP cabling
● 1000BASE-T SFP-based ports: RJ-45 connectors, 4-pair Cat 5E UTP cabling
● 100BASE-FX, 1000BASE-SX, -LX/LH, -ZX, -BX10, dense wavelength-division multiplexing (DWDM) and Coarse Wavelength-Division Multiplexing (CWDM) SFP transceivers: LC fiber connectors (single-mode or multimode fiber)
● 10GBASE-SR, LR, LRM (only C9200), ER, ZR, DWDM SFP+ transceivers: LC fiber connectors (single-mode or multimode fiber)
● SFP+ connector
● Cisco StackWise-160/80 stacking ports: copper-based Cisco StackWise cabling
● Ethernet management port: RJ-45 connectors, 4-pair Cat 5 UTP cabling
● Management console port: RJ-45-to-DB9 cable for PC connections, USB-C adaptor, USB adaptor
|
| Power connectors |
● Internal power supply connector: The internal power supply is an auto-ranging unit. It supports input voltages between 100 and 240 VAC. Use the supplied AC power cord to connect the AC power connector to an AC power outlet.
|
Para obter as informações mais recentes sobre compatibilidade do módulo transceptor Cisco, consulte https://www.cisco.com/c/en/us/td/docs/interfaces_modules/transceiver_modules/compatibility/matrix/TMG_CM_Tool_User_Manual.html .
Suporte a gerenciamento e padrões
A Tabela 14 mostra o suporte a gerenciamento e padrões para Switches Cisco Catalyst 9200 Series.
Tabela 14. Gerenciamentoe suporte a padrões *
| Descrição |
Especificação |
|
| Gestão |
BRIDGE-MIB CISCO-BRIDGE-EXT-MIB MIB CISCO-GRANDE-ARQUIVO-MIB CISCO-CABLE-DIAG-MIB CISCO-CALLHOME-MIB CISCO-CEF-MIB CISCO-CIRCUITO-INTERFACE-MIB CISCO-CONFIG-COPY-MIB CISCO-CONFIG-MAN-MIB CISCO-DEVICE-LOCALIZAÇÃO-MIB CISCO-DHCP-SNOOPING-MIB CISCO-EIGRP-MIB EVENTO EMBUTIDO CISCO-MGR-MIB CISCO-ENTITY-FRU-CONTROL-MIB MIB CISCO-ENTITY-SENSOR-MIB CISCO-ENTITY-VENDORTYPE-OID-MIB MIB CISCO-ERR-DISABLE CISCO-FLASH-MIB CISCO-FLOW-MONITOR-MIB CISCO-FTP-CLIENT-MIB CISCO-HSRP-EXT-MIB CISCO-HSRP-MIB CISCO-IETF-BFD-MIB CISCO-IETF-PPVPN-MPLS-VPN-MIB CISCO-IETF-PW-MPLS-MIB MIB CISCO-SE-EXTENSÃO CISCO-IGMP-FILTER-MIB CISCO-IMAGEM-LICENÇA-MGMT-MIB CISCO-IMAGE-MIB CISCO-IP-CBR-METRICS-MIB CISCO-IP-STAT-MIB CISCO-IP-TAP-MIB CISCO-IP-URPF-MIB CISCO-IPSEC-FLOW-MONITOR-MIB CISCO-IPSEC-MIB CISCO-IPSEC-PROVISIONING-MIB CISCO-IPSLA-AUTOMEASURE-MIB CISCO-IPSLA-ECHO-MIB CISCO-IPSLA-JITTER-MIB CISCO-L2-CONTROL-MIB CISCO-L2L3-INTERFACE-CONFIG-MIB CISCO-LAG-MIB CISCO-LICENSE-MGMT-MIB CISCO-LOCAL-AUTH-USUÁRIO-MIB CISCO-MAC-NOTIFICATION-MIB CISCO-MDI-METRICS-MIB CISCO-MEDIA-METRICS-MIB CISCO-MEMORY-POOL-MIB CISCO-MPLS-LSR-EXT-STD-MIB CISCO-NBAR-PROTOCOLO-DESCOBERTA-MIB |
CISCO-NTP-MIB CISCO-PAGP-MIB CISCO-PORT-SECURITY-MIB CISCO-PORT-STORM-CONTROL-MIB CISCO-POWER-ETHERNET-EXT-MIB CISCO-PRIVATE-VLAN-MIB CISCO-PROCESS-MIB CISCO-PRODUCTS-MIB CISCO-RF-MIB CISCO-RTP-METRICS-MIB CISCO-RTTMON-ICMP-MIB CISCO-STACKWISE-MIB CISCO-STP-EXTENSÕES-MIB CISCO-SYSLOG-MIB CISCO-TCP-MIB CISCO-UDLDP-MIB MIB CISCO-VLAN-IFTABLE-RELATIONSHIP-MIB ENTITY-MIB HC-ALARM-MIB HC-RMON-MIB IEEE8023-LAG-MIB IF-MIB IP-FORWARD-MIB IP-MIB LLDP-EXT-MED-MIB LLDP-MIB MAU-MIB MPLS-L3VPN-STD-MIB MPLS-LSR-STD-MIB MPLS-VPN-MIB VELHO-CISCO-CHASSIS-MIB OLD-CISCO-CPU-MIB MIB-CISCO-INTERFACES-MIB OLD-CISCO-IP-MIB MIB DE MEMÓRIA-CISCO-VELHA VELHO-CISCO-SYS-MIB OLD-CISCO-TCP-MIB VELHO-CISCO-TS-MIB POWER-ETHERNET-MIB RFC1213-MIB RMON-MIB RMON2-MIB SMON-MIB SNMPv2-MIB SONET-MIB TCP-MIB UDP-MIB |
| Padrões |
EEE 802.1s IEEE 802.1w IEEE 802.1x IEEE 802.1x-Rev IEEE 802.3ad IEEE 802.3af IEEE 802.3at IEEE 802.3x full duplex nas portas 10BASE-T, 100BASE-TX e 1000BASE-T Protocolo IEEE 802.1D Spanning Tree Priorização IEEE 802.1p CoS VLAN IEEE 802.1Q IEEE 802.3 10BASE-T specification IEEE 802.3u 100BASE-TX specification IEEE 802.3ab 1000BASE-T specification IEEE 802.3z 1000BASE-X specification |
RMON I and II standards SNMPv1, v2c, and v3 |
Power supply specifications
Table 15 lists the power specifications for Cisco Catalyst 9200 Series switches based on the kind of power supply used.
Table 15. Power supply specifications
| Description |
Specification |
|||||
|
|
PWR-C5-125WAC |
PWR-C6-125WAC |
PWR-C5-600WAC |
PWR-C6-600WAC |
PWR-C5-1KWAC |
PWR-C6-1KWAC |
| Power supply rated maximum |
125W |
125W |
600W |
600W |
1000W |
1000W |
| Total output BTU |
426.5 BTU/hr, 125W |
426.5 BTU/hr, 125W |
2047.3 BTU/hr, 600W |
2047.3 BTU/hr, 600W |
3412 BTU/hr, 1000W |
3412 BTU/hr, 1000W |
| Input-voltage range and frequency |
100 to 240 VAC, 50 to 60 Hz |
100 to 240 VAC, 50 to 60 Hz |
100 to 240 VAC, 50 to 60 Hz |
100 to 240 VAC, 50 to 60 Hz |
100 to 240 VAC, 50 to 60 Hz |
100 to 240 VAC, 50 to 60 Hz |
| Input current |
1.6-0.7A |
1.6-0.7A |
7-2.8A |
7-2.8A |
12-6A |
12-6A |
| Output ratings |
12V at 10.5A |
12V at 10.5A |
54V at 11.1A |
54V at 11.1A |
54V at 16.5A |
54V at 16.5A |
| Output holdup time |
20 ms minimum at 100 VAC |
20 ms minimum at 100 VAC |
20 ms minimum at 100 VAC |
20 ms minimum at 100 VAC |
20 ms minimum at 100 VAC |
20 ms minimum at 100 VAC |
| Power-supply input receptacles |
IEC 320-C14 (IEC60320-C14) |
IEC 320-C14 (IEC60320-C14) |
IEC 320-C16 (IEC60320-C16) |
IEC 320-C16 (IEC60320-C16) |
IEC 320-C16 (IEC60320-C16) |
IEC 320-C16 (IEC60320-C16) |
| Power cord rating |
10A |
10A |
15A |
15A |
15A |
15A |
| Physical specifications |
(H x W x D): 1.58” x 4.0” x 7.6” Weight: 1.5 lb (0.68 kg) |
(H x W x D): 1.58” x 4.0” x 7.6” Weight: 1.5 lb (0.68 kg) |
(H x W x D): 1.58” x 4.0” x 7.6” Weight: 1.7 lb (0.77 kg) |
(H x W x D): 1.58” x 4.0” x 7.6” Weight: 1.7 lb (0.77 kg) |
(H x W x D): 1.58” x 4.0” x 7.6” Weight: 2 lb (0.9 kg) |
(H x W x D): 1.58” x 4.0” x 7.6” Weight: 2 lb (0.9 kg) |
| Supported Product Family |
C9200, C9200L |
C9200 |
C9200, C9200L |
C9200 |
C9200, C9200L |
C9200 |
| Operating temperature |
Normal operating temperature* and altitudes:
● -5°C to +45°C, up to 5000 feet (1500m)
● -5°C to +40°C, up to 10,000 feet (3000m)
* Minimum ambient temperature for cold start is 32°F (0°C) Short-term* exceptional conditions:
● -5°C to +50°C, up to 5000 feet (1500m)
● -5°C to +45°C, up to 10,000 feet (3000m)
● -5°C to +45°C, at sea level with single fan failure
* Not more than following in one-year period: 96 consecutive hours, or 360 hours total, or 15 occurrences |
|||||
| Storage temperature |
-40° to 158°F (-40° to 70°C) |
|||||
| Relative humidity operating and nonoperating noncondensing |
5% to 90% noncondensing |
|||||
| Altitude |
10,000 ft. (3000 meters), up to 45°C |
|||||
| EMI and EMC compliance |
FCC Part 15 (CFR 47) Class A ICES-003 Class A EN 55032 Class A CISPR 32 Class A AS/NZS 3548 Class A BSMI Class A VCCI Class A CISPR 35 EN 55024, EN300 386*, EN 61000-3-2, EN 61000-3-3 EN 61000-6-1 |
|||||
| Safety compliance |
UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, CCC, CE Marking |
|||||
| LED indicators |
“AC OK”: Input power to the power supply is OK “PS OK”: Output power from the power supply is OK |
|||||
* Use shielded cables for locations other than telecom centers
Power consumption of Standalone 9200 Series switches
Table 16 shows the power consumption of standalone Cisco Catalyst 9200 Series switches based on Alliance for Telecommunications Industry Solutions (ATIS) testing using Internet Mix (IMIX) distribution stream traffic, with input voltage of 115VAC at 60 Hz and no PoE loading. The values given are the maximum possible power consumption numbers under the respective test scenarios.
Table 16. Power consumption of Standalone Catalyst 9200 Series switches
| Measured P(W) |
||||||||||||||||||||
| Half port traffic |
Full port traffic |
Weighted average Pw |
No link |
PoE test (no traffic) |
||||||||||||||||
| SKU |
FEP |
Uplink |
Input |
0.01% / EEE |
10% |
30% |
50% |
100% |
0.01% / EEE |
10% |
30% |
50% |
100% |
25% |
50% |
90% |
100% |
|
||
| C9200-24T |
125W (C5/C6) |
C9200-NM-4X1G |
115VAC |
33.09 |
36.08 |
36.15 |
36.20 |
36.34 |
35.51 |
41.78 |
41.89 |
42.00 |
42.27 |
41.20 |
30.65 |
|
||||
| 230VAC |
33.15 |
35.95 |
36.00 |
36.06 |
36.19 |
35.36 |
41.50 |
41.62 |
41.74 |
42.01 |
40.94 |
30.53 |
|
|||||||
| C9200-24T |
125W |
C9200-NM—4X10G |
115VAC |
33.62 |
36.99 |
37.29 |
37.58 |
38.26 |
35.41 |
42.00 |
42.55 |
43.11 |
44.49 |
41.588 |
32.20 |
|
||||
| 230VAC |
33.70 |
36.85 |
37.13 |
37.41 |
38.10 |
35.40 |
41.75 |
42.30 |
42.85 |
44.22 |
41.364 |
31.90 |
|
|||||||
| C9200-24P |
600W (C5/C6) |
C9200-NM-4X1G |
115VAC |
43.57 |
47.37 |
47.42 |
47.47 |
47.68 |
46.82 |
53.79 |
53.91 |
54.02 |
54.30 |
53.14 |
40.75 |
150.71 |
251.67 |
416.85 |
457.98 |
|
| 230VAC |
43.38 |
46.92 |
46.95 |
47.03 |
47.18 |
46.35 |
53.23 |
53.34 |
53.45 |
53.76 |
52.59 |
40.43 |
148.14 |
247.03 |
406.62 |
446.27 |
|
|||
| C9200-24P |
600W (C5/C6) |
C9200-NM-4X10G |
115VAC |
44.62 |
48.49 |
48.79 |
49.11 |
49.88 |
47.02 |
54.18 |
54.77 |
55.34 |
56.77 |
53.72 |
42.55 |
144.60 |
245.42 |
410.22 |
451.45 |
|
| 230VAC |
44.32 |
48.06 |
48.37 |
48.66 |
49.40 |
46.41 |
53.38 |
53.99 |
54.51 |
55.96 |
52.94 |
42.26 |
142.29 |
241.14 |
400.76 |
440.37 |
|
|||
| C9200-24PXG |
600W (C6) |
C9200-NM-4X10G |
115VAC |
84.30 |
90.90 |
91.00 |
92.30 |
94.20 |
95.00 |
110.60 |
111.60 |
112.60 |
115.20 |
109.5 |
72.8 |
296.8 |
506.3 |
858.3 |
941.5 |
|
| 230VAC |
84.10 |
90.50 |
91.10 |
91.60 |
92.90 |
94.30 |
108.80 |
109.90 |
111.00 |
113.60 |
107.83 |
72.24 |
287.8 |
492.4 |
826.7 |
909.1 |
|
|||
| C9200-24PXG |
600W (C6) |
C9200-NM-2X25G |
115VAC |
83.41 |
87.59 |
88.56 |
89.19 |
90.85 |
93.96 |
101.38 |
103.32 |
104.89 |
107.22 |
101.22 |
72.52 |
187.94 |
290.47 |
452.61 |
494.88 |
|
| 230VAC |
81.90 |
86.97 |
87.68 |
88.38 |
90.03 |
92.21 |
99.79 |
101.14 |
102.45 |
105.65 |
99.62 |
71.74 |
185.45 |
283.86 |
441.83 |
480.86 |
|
|||
| C9200-24PXG |
600W (C6) |
C9200-NM-2X40G |
115VAC |
82.34 |
86.78 |
87.91 |
88.90 |
91.64 |
92.97 |
100.93 |
103.00 |
104.89 |
108.81 |
100.92 |
71.72 |
188.86 |
289.2 |
448.52 |
496.28 |
|
| 230VAC |
80.05 |
84.53 |
85.64 |
86.69 |
89.29 |
90.26 |
99.20 |
101.41 |
103.56 |
108.70 |
99.26 |
71.72 |
185.29 |
282.86 |
441.33 |
480.95 |
|
|||
| C9200-48T |
125W (C5/C6) |
C9200-NM-4X1G |
115VAC |
36.57 |
45.09 |
45.45 |
45.63 |
45.70 |
36.98 |
53.95 |
55.36 |
53.91 |
55.87 |
52.445 |
36.98 |
|
|
|
|
|
| 230VAC |
36.99 |
45.58 |
45.65 |
45.71 |
45.86 |
36.48 |
54.51 |
54.64 |
54.7 |
55.04 |
52.76 |
36.48 |
|
|
|
|
|
|||
| C9200-48T |
125W (C5/C6) |
C9200-NM-4X10G |
115VAC |
38.84 |
47.07 |
48.67 |
48.71 |
50.41 |
39.20 |
56.33 |
58.36 |
58.75 |
61.80 |
55.164 |
38.38 |
|
|
|
|
|
| 230VAC |
39.1 |
47.11 |
47.91 |
48.37 |
49.65 |
39.46 |
56.32 |
57.25 |
58.19 |
60.72 |
55.074 |
38.67 |
|
|
|
|
|
|||
| C9200-48P |
1000W (C5/C6) |
C9200-NM-4X1G |
115VAC |
56.07 |
60.25 |
60.31 |
60.36 |
60.55 |
56.45 |
69.33 |
69.46 |
69.56 |
69.87 |
68.10 |
50.42 |
262.61 |
467.50 |
812.39 |
899.99 |
|
| 230VAC |
55.66 |
59.98 |
60.05 |
60.05 |
60.27 |
56.09 |
69.07 |
69.20 |
69.30 |
69.58 |
67.83 |
50.04 |
258.08 |
457.61 |
785.35 |
867.75 |
|
|||
| C9200-48P |
1000W (C5/C6) |
C9200-NM-4X10G |
115VAC |
54.27 |
61.71 |
62.20 |
62.68 |
63.88 |
56.114 |
70.93 |
70.95 |
71.92 |
74.39 |
69.79 |
52.26 |
262.38 |
467.41 |
812.23 |
899.40 |
|
| 230VAC |
53.89 |
61.09 |
61.60 |
62.07 |
63.24 |
55.79 |
69.52 |
70.47 |
71.43 |
73.89 |
68.58 |
51.34 |
257.97 |
457.30 |
785.03 |
867.35 |
|
|||
| C9200-48PXG |
1000W (C6) |
C9200-NM-4X10G |
115VAC |
84.26 |
90.86 |
91.02 |
92.26 |
94.18 |
95.01 |
110.55 |
111.62 |
112.62 |
115.2 |
109.46 |
72.3 |
296.81 |
506.33 |
858.27 |
941.49 |
|
| 230VAC |
84.14 |
90.52 |
91.05 |
91.57 |
92.85 |
94.25 |
108.84 |
109.94 |
111 |
113.6 |
107.86 |
73.2 |
287.79 |
492.42 |
826.74 |
909.07 |
|
|||
| C9200-48PXG |
1000W (C6) |
C9200-NM-2X25G |
115VAC |
87.84 |
95.23 |
95.98 |
96.69 |
98.34 |
99.25 |
113.66 |
115.37 |
116.7 |
120.91 |
112.94 |
77.57 |
300.71 |
513.82 |
872.63 |
957.36 |
|
| 230VAC |
87.12 |
94.14 |
94.79 |
95.42 |
96.99 |
97.59 |
111.99 |
113.52 |
114.86 |
117.82 |
111.13 |
76.53 |
290.61 |
492.91 |
826.5 |
910.08 |
|
|||
| C9200-48PXG |
1000W (C6) |
C9200-NM-2X40G |
115VAC |
88.01 |
94.35 |
95.5 |
96.48 |
99.36 |
98.72 |
113.2 |
115.13 |
117.08 |
121.84 |
112.61 |
76.84 |
296.86 |
503.87 |
861.87 |
957.4 |
|
| 230VAC |
87.02 |
93.09 |
94.15 |
95.16 |
97.79 |
97.28 |
111.43 |
113.57 |
115.66 |
120.67 |
110.94 |
75.84 |
291.54 |
491.67 |
824.85 |
909.78 |
|
|||
| C9200L-24T-4G |
125W (C5) |
Fixed |
115VAC |
30.03 |
32.15 |
32.17 |
32.2 |
32.33 |
32.03 |
35.90 |
35.98 |
36.06 |
36.23 |
35.546 |
27.39 |
|
|
|
|
|
| 230VAC |
29.81 |
32.26 |
32.23 |
32.22 |
32.35 |
31.86 |
35.86 |
35.94 |
36.03 |
36.28 |
35.502 |
27.50 |
|
|
|
|
|
|||
| C9200L-24P-4G |
600W (C5) |
Fixed |
115VAC |
39.28 |
43.98 |
44.04 |
44.08 |
44.22 |
38.95 |
48.47 |
48.6 |
48.74 |
49.00 |
47.571 |
39.59 |
153.06 |
256.56 |
423.44 |
466.34 |
|
| 230VAC |
38.88 |
43.6 |
43.66 |
43.69 |
43.83 |
38.57 |
48.09 |
48.22 |
48.35 |
48.62 |
47.191 |
39.20 |
150.51 |
252.10 |
413.89 |
455.15 |
|
|||
| C9200L-24T-4X |
125W (C5) |
Fixed |
115VAC |
30.99 |
31.98 |
32.21 |
32.43 |
33.04 |
33.29 |
36.62 |
37.02 |
37.47 |
38.6 |
36.485 |
27.82 |
|
|
|
|
|
| 230VAC |
30.98 |
32.02 |
32.24 |
32.46 |
33.02 |
33.24 |
36.59 |
36.96 |
37.41 |
38.52 |
36.448 |
27.90 |
|
|
|
|
|
|||
| C9200L-24P-4X |
600W (C5) |
Fixed |
115VAC |
42.83 |
44.15 |
44.62 |
44.72 |
45.39 |
45.45 |
51.08 |
51.52 |
52.2 |
53.49 |
50.758 |
40.17 |
144.82 |
241.99 |
401.32 |
445.35 |
|
| 230VAC |
42.36 |
44.19 |
44.47 |
44.61 |
45.28 |
44.6 |
49.33 |
49.91 |
50.36 |
51.51 |
49.075 |
39.48 |
142.32 |
237.52 |
392.77 |
434.06 |
|
|||
| C9200L-48T-4G |
125W (C5) |
Fixed |
115VAC |
33.85 |
40.11 |
40.20 |
40.24 |
40.34 |
32.74 |
46.65 |
46.88 |
46.96 |
47.33 |
45.327 |
33.85 |
|
|
|
|
|
| 230VAC |
33.62 |
40.5 |
40.57 |
40.63 |
40.74 |
33.06 |
46.8 |
46.91 |
47.05 |
47.49 |
45.495 |
34.16 |
|
|
|
|
||||
| C9200L-48P-4G |
1000W (C5) |
Fixed |
115VAC |
45.07 |
52.15 |
52.22 |
52.28 |
52.44 |
44.6 |
58.59 |
58.7 |
58.81 |
59.1 |
57.242 |
45.82 |
270.96 |
484.59 |
842.07 |
933.03 |
|
| 230VAC |
44.55 |
51.5 |
51.55 |
51.6 |
51.77 |
44.08 |
57.82 |
57.91 |
58.04 |
58.29 |
56.493 |
45.17 |
266.35 |
474.24 |
814.85 |
899.58 |
||||
| C9200L-48T-4X |
125W (C5) |
Fixed |
115VAC |
35.52 |
42.36 |
42.9 |
43.35 |
43.69 |
35.06 |
49.27 |
50.24 |
51.19 |
53.60 |
48.282 |
36.08 |
|
|
|
|
|
| 230VAC |
35.84 |
42.60 |
43.09 |
43.58 |
44.81 |
35.27 |
49.41 |
50.36 |
51.33 |
53.67 |
48.422 |
36.38 |
|
|
|
|
||||
| C9200L-48P-4X |
1000W (C5) |
Fixed |
115VAC |
53.12 |
56.89 |
57.34 |
57.80 |
57.81 |
55.22 |
63.92 |
64.86 |
65.84 |
68.36 |
63.494 |
50.31 |
262.59 |
463.36 |
789.46 |
872.6 |
|
| 230VAC |
52.63 |
56.37 |
56.82 |
57.3 |
58.47 |
54.71 |
63.41 |
64.32 |
65.27 |
67.64 |
62.963 |
50.02 |
258.64 |
453.81 |
766.04 |
843.89 |
||||
| C9200L-48PXG-4X |
1000W (C5) |
Fixed |
115VAC |
82.60 |
87.80 |
88.28 |
88.76 |
89.95 |
92.56 |
103.53 |
104.55 |
105.57 |
108.19 |
102.90 |
72.14 |
291.62 |
496.85 |
842.43 |
930.11 |
|
| 230VAC |
81.77 |
86.62 |
87.11 |
87.60 |
88.82 |
91.87 |
102.05 |
103.02 |
103.98 |
106.40 |
101.47 |
72.50 |
286.71 |
486.25 |
814.71 |
898.24 |
||||
| C9200L-24PXG-4X |
600W (C5) |
Fixed |
115VAC |
70.94 |
73.88 |
74.37 |
74.84 |
76.02 |
77.37 |
84.12 |
85.06 |
86.00 |
88.32 |
83.86 |
64.54 |
173.05 |
271.04 |
431.68 |
472.39 |
|
| 230VAC |
70.10 |
73.04 |
73.62 |
74.07 |
75.15 |
76.74 |
82.96 |
83.86 |
84.78 |
87.09 |
82.75 |
64.04 |
170.02 |
265.51 |
420.96 |
459.88 |
||||
| C9200L-48PXG-2Y |
1000W (C5) |
Fixed |
115VAC |
81.81 |
85.14 |
85.81 |
86.49 |
88.08 |
89.40 |
96.32 |
97.51 |
98.71 |
101.76 |
96.17 |
71.45 |
294.56 |
500.25 |
846.33 |
934.08 |
|
| 230VAC |
79.59 |
82.94 |
83.64 |
84.28 |
85.81 |
88.20 |
95.17 |
96.36 |
97.52 |
100.40 |
95.00 |
70.28 |
283.88 |
483.54 |
812.20 |
894.11 |
||||
| C9200L-24PXG-2Y |
600W (C5) |
Fixed |
115VAC |
70.54 |
73.04 |
73.78 |
74.46 |
76.10 |
76.25 |
83.50 |
84.78 |
86.09 |
89.26 |
83.35 |
65.58 |
178.82 |
280.13 |
446.82 |
489.62 |
|
| 230VAC |
68.89 |
72.02 |
72.66 |
73.35 |
74.93 |
75.32 |
82.00 |
83.34 |
84.64 |
87.87 |
81.92 |
65.01 |
175.55 |
274.59 |
434.38 |
475.39 |
||||
Safety and compliance
Table 17 lists the safety and compliance information for Cisco Catalyst 9200 Series switches.
Table 17. Safety and compliance information
| Description |
Specification |
| Safety certifications |
● IEC 60950-1
● UL 60950-1
● CAN/CSA C22.2 No. 60950-1
● EN 60950-1
● AS/NZS 60950.1
● Class I Equipment
|
| Electromagnetic emissions certifications |
● 47 CFR Part 15
● CISPR 22 Class A
● CISPR 32 Class A
● CNS 13438
● EN 300 386
*
● EN 55022 Class A
● EN 55032 Class A
● EN61000-3-2
● EN61000-3-3
● ICES-003 Class A
● KN 32
● TCVN 7189 Class A
● V-3 Class A
● CISPR 24
● EN 300 386
*
● EN 55024
● KN 35
● TCVN 7317
|
| Environmental |
Reduction of Hazardous Substances (ROHS) 5 |
* Use shielded cables for locations other than telecom centers
Cisco enhanced limited lifetime hardware warranty
Cisco Catalyst 9200 Series switches come with a Cisco Enhanced Limited Lifetime Warranty (E-LLW) that includes Next-Business-Day (NBD) delivery of replacement hardware where available and 90 days of 8x5 Cisco Technical Assistance Center (TAC) support.
Your formal warranty statement, including the warranty applicable to Cisco software, appears in the information packet that accompanies your Cisco product. We encourage you to review the warranty statement shipped with your specific product carefully before use.
Cisco reserves the right to refund the purchase price as its exclusive warranty remedy.
For further information about warranty terms, visit https://www.cisco.com/go/warranty. Table 18 provides information about the E-LLW.
|
|
Cisco E-LLW |
| Devices covered |
Applies to Cisco Catalyst 9200 Series switches. |
| Warranty duration |
As long as the original customer owns the product. |
| End-of-life policy |
In the event of discontinuance of product manufacture, Cisco warranty support is limited to 5 years from the announcement of discontinuance. |
| Hardware replacement |
Cisco or its service center will use commercially reasonable efforts to ship a replacement for NBD delivery, where available. Otherwise, a replacement will be shipped within 10 working days after receipt of the Return Materials Authorization (RMA) request. Actual delivery times might vary depending on customer location. |
| Effective date |
Hardware warranty commences from the date of shipment to customer (and in case of resale by a Cisco reseller, not more than 90 days after original shipment by Cisco). |
| TAC support |
Cisco will provide during business hours, 8 hours per day, 5 days per week, basic configuration, diagnosis, and troubleshooting of device-level problems for up to a 90-day period from the date of shipment of the originally purchased Cisco Catalyst 9200 Series product. This support does not include solution or network-level support beyond the specific device under consideration. |
| Cisco.com access |
Warranty allows guest access only to Cisco.com. |
Cisco services for next-generation Cisco Catalyst switches
Achieve infrastructure excellence faster and with less risk. Cisco Catalyst 9000 Switch Services provide expert guidance to help you successfully deploy, manage and support the Cisco Catalyst 9000 switches. With unmatched networking expertise, best practices and innovative tools, we can help you reduce overall upgrade, refresh, and migration costs as you introduce new hardware, software and protocols into the network. Offering a comprehensive lifecycle of services – from implementation, optimization, technical and managed services – Cisco experts help you minimize disruption and achieve operational excellence to extract maximum value from your Cisco DNA ready infrastructure.
Learn more about Cisco Services for Enterprise Networks
Software Policy for Cisco Catalyst 9200 Series switches
Software Policy for Network Stack Components
Customers with the Network Essentials Stack and Network Advantage Stack software feature sets are provided with maintenance updates and bug fixes designed to maintain compliance of the software. This includes compliance with published specifications, release notes, and industry standards as long as the original end user continues to own or use the product or up to one year from the end-of-sale date for the product, whichever occurs earlier.
Cisco Embedded Support for Cisco DNA Term Components
Cisco Embedded Support delivers the right support for Cisco software products and suites. It will keep your business applications performing as expected and protect your investment. Cisco Embedded Support for the Cisco DNA Essentials and Cisco DNA Advantage term components is included. Cisco Embedded Support provides access to TAC support, major software updates, maintenance and minor software releases, and the Cisco Embedded Support site, for increased productivity with anytime access.
Ordering information
Table 19 lists ordering information for Cisco Catalyst 9200 Series switches. To place an order, visit the Cisco Ordering home page at https://www.cisco.com/en/US/ordering/or13/or8/order_customer_help_how_to_order_listing.html.
Table 19. Ordering information
| Switches |
|
| Product number |
Product description |
| C9200-24T-A |
Catalyst 9200 24-port Data Switch, Network Advantage |
| C9200-24T-E |
Catalyst 9200 24-port Data Switch, Network Essentials |
| C9200-24P-A |
Catalyst 9200 24-port PoE+ Switch, Network Advantage |
| C9200-24P-E |
Catalyst 9200 24-port PoE+ Switch. Network Essentials |
| C9200-24PB-A |
Catalyst 9200 24-port PoE+, enhanced VRF, Network Advantage |
| C9200-24PXG-E |
Catalyst 9200 24-port 8xmGig, 16x1G, PoE+, Network Essentials |
| C9200-24PXG-A |
Catalyst 9200 24-port 8xmGig, 16x1G, PoE+, Network Advantage |
| C9200-48T-A |
Catalyst 9200 48-port Data Switch, Network Advantage |
| C9200-48T-E |
Catalyst 9200 48-port Data Switch, Network Essentials |
| C9200-48P-A |
Catalyst 9200 48-port PoE+ Switch, Network Advantage |
| C9200-48P-E |
Catalyst 9200 48-port PoE+ Switch, Network Essentials |
| C9200-48PB-A |
Catalyst 9200 48-port PoE+, enhanced VRF, Network Advantage |
| C9200-48PXG-E |
Catalyst 9200 48-port 8xmGig, 40x1G, PoE+, Network Essentials |
| C9200-48PXG-A |
Catalyst 9200 48-port 8xmGig, 40x1G, PoE+, Network Advantage |
| C9200L-24T-4G-A |
Catalyst 9200L 24-port Data 4x1G uplink Switch, Network Advantage |
| C9200L-24T-4G-E |
Catalyst 9200L 24-port Data 4x1G uplink Switch, Network Essentials |
| C9200L-24P-4G-A |
Catalyst 9200L 24-port PoE+ 4x1G uplink Switch, Network Advantage |
| C9200L-24P-4G-E |
Catalyst 9200L 24-port PoE+ 4x1G uplink Switch, Network Essentials |
| C9200L-48T-4G-A |
Catalyst 9200L 48-port Data 4x1G uplink Switch, Network Advantage |
| C9200L-48T-4G-E |
Catalyst 9200L 48-port Data 4x1G uplink Switch, Network Essentials |
| C9200L-48P-4G-A |
Catalyst 9200L48-port PoE+ 4x1G uplink Switch, Network Advantage |
| C9200L-48P-4G-E |
Catalyst 9200L48-port PoE+ 4x1G uplink Switch, Network Essentials |
| C9200L-24T-4X-A |
Catalyst 9200L 24-port Data 4x10G uplink Switch, Network Advantage |
| C9200L-24T-4X-E |
Catalyst 9200L 24-port Data 4x10G uplink Switch, Network Essentials |
| C9200L-24P-4X-A |
Catalyst 9200L 24-port PoE+ 4x10G uplink Switch, Network Advantage |
| C9200L-24P-4X-E |
Catalyst 9200L 24-port PoE+ 4x10G uplink Switch, Network Essentials |
| C9200L-48T-4X-A |
Catalyst 9200L 48-port Data 4x10G uplink Switch, Network Advantage |
| C9200L-48T-4X-E |
Catalyst 9200L 48-port Data 4x10G uplink Switch, Network Essentials |
| C9200L-48P-4X-A |
Catalyst 9200L 48-port PoE+ 4x10G uplink Switch, Network Advantage |
| C9200L-48P-4X-E |
Catalyst 9200L 48-port PoE+ 4x10G uplink Switch, Network Essentials |
| C9200L-24PXG-4X-E |
Catalyst 9200L 24-port 8xmGig, 16x1G, 4x10G, PoE+, Network Essentials |
| C9200L-24PXG-4X-A |
Catalyst 9200L 24-port 8xmGig, 16x1G, 4x10G, PoE+, Network Advantage |
| C9200L-48PXG-4X-E |
Catalyst 9200L 48-port 12xmGig, 36x1G, 4x10G PoE+, Network Essentials |
| C9200L-48PXG-4X-A |
Catalyst 9200L 48-port 12xmGig, 36x1G, 4x10G PoE+, Network Advantage |
| C9200L-24PXG-2Y-E |
Catalyst 9200L 24-port 8xmGig, 16x1G, 2x25G, PoE+, Network Essentials |
| C9200L-24PXG-2Y-A |
Catalyst 9200L 24-port 8xmGig, 16x1G, 2x25G, PoE+, Network Advantage |
| C9200L-48PXG-2Y-E |
Catalyst 9200L 48-port 8xmGig, 40x1G, 2x25G PoE+, Network Essentials |
| C9200L-48PXG-2Y-A |
Catalyst 9200L 48-port 8xmGig, 40x1G, 2x25G PoE+, Network Advantage |
| Network modules |
|
| Product number |
Product description |
| C9200-NM-2Y (=) |
Catalyst 9200 2 x 25 GE Network Module, spare |
| C9200-NM-2Q (=) |
Catalyst 9200 2 x 40GE Network Module, spare |
| C9200-NM-4G (=) |
Catalyst 9200 4 x 1GE Network Module, spare |
| C9200-NM-4X (=) |
Catalyst 9200 4 x 10GE Network Module, spare |
| C9200-NM-BLANK |
Catalyst 9200 BLANK Network Module |
| StackWise-80 and StackWise-160 Kit and cables |
|
| Product number |
Product description |
| C9200-STACK-KIT= |
C9200 Stack Kit Spare |
| C9200L-STACK-KIT= |
C9200L Stack Kit Spare |
| STACK-T4-50CM |
50CM Type 3 Stacking Cable |
| STACK-T4-50CM= |
50CM Type 3 Stacking Cable, spare |
| STACK-T4-1M |
1M Type 3 Stacking Cable |
| STACK-T4-1M= |
1M Type 3 Stacking Cable, spare |
| STACK-T4-3M |
3M Type 3 Stacking Cable |
| STACK-T4-3M= |
3M Type 3 Stacking Cable, spare |
| Software licenses |
|
| Product number |
Product description |
| C9200-DNA-P-24 |
C9200 Cisco DNA Premier Term, 24-Port: Includes Term Licenses for Cisco DNA Advantage, 25 ISE Base and 25 ISE Plus Endpoints, 25 Stealthwatch Flows (including Virtual Flow Collector and Management Console). Requires separate purchase of ISE appliance/ISE VM and Cisco DNA Center appliance |
| C9200-DNA-P-24-3Y |
C9200 Cisco DNA Premier, 24-port, 3Y Term – Cisco DNA, 25 ISE PLS and ISE BASE, 25 SWATCH |
| C9200-DNA-P-24-5Y |
C9200 Cisco DNA Premier, 24-port, 5Y Term – Cisco DNA, 25 ISE PLS and ISE BASE, 25 SWATCH |
| C9200-DNA-P-24-7Y |
C9200 Cisco DNA Premier, 24-port, 7Y Term – Cisco DNA, 25 ISE PLS and ISE BASE, 25 SWATCH |
| C9200-DNA-P-48 |
C9200 Cisco DNA Premier Term, 48-Port: Includes Term Licenses for Cisco DNA Advantage, 25 ISE Base and 25 ISE Plus Endpoints, 25 Stealthwatch Flows (including Virtual Flow Collector and Management Console). Requires separate purchase of ISE appliance/ISE VM and Cisco DNA Center appliance |
| C9200-DNA-P-48 -3Y |
C9200 Cisco DNA Premier, 48-port, 3Y Term – Cisco DNA, 25 ISE PLS and ISE BASE, 25 SWATCH |
| C9200-DNA-P-48 -5Y |
C9200 Cisco DNA Premier, 48-port, 5Y Term – Cisco DNA, 25 ISE PLS and ISE BASE, 25 SWATCH |
| C9200-DNA-P-48 -7Y |
C9200 Cisco DNA Premier, 48-port, 7Y Term – Cisco DNA, 25 ISE PLS and ISE BASE, 25 SWATCH |
| C9200-DNA-E-24 |
C9200 Cisco DNA Essentials Term 24-port |
| C9200-DNA-E-24-3Y |
C9200 Cisco DNA Essentials, 24-port, 3 Year Term license |
| C9200-DNA-E-24-5Y |
C9200 Cisco DNA Essentials, 24-port, 5 Year Term license |
| C9200-DNA-E-24-7Y |
C9200 Cisco DNA Essentials, 24-port, 7 Year Term license |
| C9200-DNA-E-48 |
C9200 Cisco DNA Essentials Term 48-port |
| C9200-DNA-E-48-3Y |
C9200 Cisco DNA Essentials, 48-port, 3 Year Term license |
| C9200-DNA-E-48-5Y |
C9200 Cisco DNA Essentials, 48-port, 5 Year Term license |
| C9200-DNA-E-48-7Y |
C9200 Cisco DNA Essentials, 48-port, 7 Year Term license |
| C9200-DNA-A-24 |
C9200 Cisco DNA Advantage Term 24-port |
| C9200-DNA-A-24-3Y |
C9200 Cisco DNA Advantage, 24-port, 3 Year Term license |
| C9200-DNA-A-24-5Y |
C9200 Cisco DNA Advantage, 24-port, 5 Year Term license |
| C9200-DNA-A-24-7Y |
C9200 Cisco DNA Advantage, 24-port, 7 Year Term license |
| C9200-DNA-A-48 |
C9200 Cisco DNA Advantage Term 48-port |
| C9200-DNA-A-48-3Y |
C9200 Cisco DNA Advantage, 48-port, 3 Year Term license |
| C9200-DNA-A-48-5Y |
C9200 Cisco DNA Advantage, 48-port, 5 Year Term license |
| C9200-DNA-A-48-7Y |
C9200 Cisco DNA Advantage, 48-port, 7 Year Term license |
| C9200L-DNA-P-24 |
C9200L Cisco DNA Premier Term, 24-Port: Includes Term Licenses for Cisco DNA Advantage, 25 ISE Base and 25 ISE Plus Endpoints, 25 Stealthwatch Flows (including Virtual Flow Collector and Management Console). Requires separate purchase of ISE appliance/ISE VM and Cisco DNA Center appliance |
| C9200L-DNA-P-24-3Y |
C9200L Cisco DNA Premier, 24-port, 3Y Term – Cisco DNA, 25 ISE PLS and ISE BASE, 25 SWATCH |
| C9200L-DNA-P-24-5Y |
C9200L Cisco DNA Premier, 24-port, 5Y Term – Cisco DNA, 25 ISE PLS and ISE BASE, 25 SWATCH |
| C9200L-DNA-P-24-7Y |
C9200L Cisco DNA Premier, 24-port, 7Y Term – Cisco DNA, 25 ISE PLS and ISE BASE, 25 SWATCH |
| C9200L-DNA-P-48 |
C9200L Cisco DNA Premier Term, 48-Port: Includes Term Licenses for Cisco DNA Advantage, 25 ISE Base and 25 ISE Plus Endpoints, 25 Stealthwatch Flows (including Virtual Flow Collector and Management Console). Requires separate purchase of ISE appliance/ISE VM and Cisco DNA Center appliance |
| C9200L-DNA-P-48-3Y |
C9200L Cisco DNA Premier, 48-port, 3Y Term – Cisco DNA, 25 ISE PLS and ISE BASE, 25 SWATCH |
| C9200L-DNA-P-48 -5Y |
C9200L Cisco DNA Premier, 48-port, 5Y Term – Cisco DNA, 25 ISE PLS and ISE BASE, 25 SWATCH |
| C9200L-DNA-P-48 -7Y |
C9200L Cisco DNA Premier, 48-port, 7Y Term – Cisco DNA, 25 ISE PLS and ISE BASE, 25 SWATCH |
| C9200L-DNA-E-24 |
C9200L Cisco DNA Essentials Term 24-port |
| C9200L-DNA-E-24-3Y |
C9200L Cisco DNA Essentials, 24-port, 3 Year Term license |
| C9200L-DNA-E-24-5Y |
C9200L Cisco DNA Essentials, 24-port, 5 Year Term license |
| C9200L-DNA-E-24-7Y |
C9200L Cisco DNA Essentials, 24-port, 7 Year Term license |
| C9200L-DNA-E-48 |
C9200L Cisco DNA Essentials Term 48-port |
| C9200L-DNA-E-48-3Y |
C9200L Cisco DNA Essentials, 48-port, 3 Year Term license |
| C9200L-DNA-E-48-5Y |
C9200L Cisco DNA Essentials, 48-port, 5 Year Term license |
| C9200L-DNA-E-48-7Y |
C9200L Cisco DNA Essentials, 48-port, 7 Year Term license |
| C9200L-DNA-A-24 |
C9200L Cisco DNA Advantage Term 24-port |
| C9200L-DNA-A-24-3Y |
C9200L Cisco DNA Advantage, 24-port, 3 Year Term license |
| C9200L-DNA-A-24-5Y |
C9200L Cisco DNA Advantage, 24-port, 5 Year Term license |
| C9200L-DNA-A-24-7Y |
C9200L Cisco DNA Advantage, 24-port, 7 Year Term license |
| C9200L-DNA-A-48 |
C9200L Cisco DNA Advantage Term 48-port |
| C9200L-DNA-A-48-3Y |
C9200L Cisco DNA Advantage, 48-port, 3 Year Term license |
| C9200L-DNA-A-48-5Y |
C9200L Cisco DNA Advantage, 48-port, 5 Year Term license |
| C9200L-DNA-A-48-7Y |
C9200L Cisco DNA Advantage, 48-port, 7 Year Term license |
| C9200-LIC= |
Electronic Cisco DNA Upgrade License for C9200 switches. Note: when upgrading from Cisco DNA Essentials to Cisco DNA Advantage, Network Essentials is upgraded to Network Advantage |
| C9200-24-E-A |
C9200 24-port NW and DNA Essentials to NW and DNA Advantage Upgrade |
| C9200-24-E-A-3 |
24-port NW and Cisco DNA Ess to NW and DNA Adv Upgrade License 3Y |
| C9200-24-E-A-5 |
24-port NW and Cisco DNA Ess to NW and DNA Adv Upgrade License 5Y |
| C9200-24-E-A-7 |
24-port NW and Cisco DNA Ess to NW and DNA Adv Upgrade License 7Y |
| C9200-48-E-A |
C9200 48-port NW and DNA Essentials to NW and DNA Advantage Upgrade |
| C9200-48-E-A-3 |
48-port NW and Cisco DNA Ess to NW and DNA Adv Upgrade License 3Y |
| C9200-48-E-A-5 |
48-port NW and Cisco DNA Ess to NW and DNA Adv Upgrade License 5Y |
| C9200-48-E-A-7 |
48-port NW and Cisco DNA Ess to NW and DNA Adv Upgrade License 7Y |
| C9200L-LIC= |
Electronic Cisco DNA Upgrade License for C9200L switches. Note: when upgrading from Cisco DNA Essentials to Cisco DNA Advantage, Network Essentials is upgraded to Network Advantage |
| C9200L-24-E-A |
C9200L 24-port NW and DNA Essentials to NW and DNA Advantage Upgrade |
| C9200L-24-E-A-3 |
24-port NW and Cisco DNA Ess to NW and DNA Adv Upgrade License 3Y |
| C9200L-24-E-A-5 |
24-port NW and Cisco DNA Ess to NW and DNA Adv Upgrade License 5Y |
| C9200L-24-E-A-7 |
24-port NW and Cisco DNA Ess to NW and DNA Adv Upgrade License 7Y |
| C9200L-48-E-A |
C9200L 48-port NW and DNA Essentials to NW and DNA Advantage Upgrade |
| C9200L-48-E-A-3 |
48-port NW and Cisco DNA Ess to NW and DNA Adv Upgrade License 3Y |
| C9200L-48-E-A-5 |
48-port NW and Cisco DNA Ess to NW and DNA Adv Upgrade License 5Y |
| C9200L-48-E-A-7 |
48-port NW and Cisco DNA Ess to NW and DNA Adv Upgrade License 7Y |
| Suprimentos de energia |
|
| Número de produto |
Descrição do Produto |
| PWR-C5-125WAC (=) |
Fonte de alimentação 125 W AC Config 5 |
| PWR-C5-125WAC / 2 |
Fonte de alimentação 125 W AC Config 5 - Fonte de alimentação secundária |
| PWR-C5-600WAC (=) |
Fonte de alimentação 5W de configuração CA de 600W |
| PWR-C5-600WAC / 2 |
Fonte de alimentação 600 W AC Config 5 - Fonte de alimentação secundária |
| PWR-C5-1KWAC (=) |
1KW AC Config 5 Fonte de alimentação |
| PWR-C5-1KWAC / 2 |
Fonte de alimentação 1KW AC Config 5 - Fonte de alimentação secundária |
| PWR-C6-125WAC (=) |
Fonte de alimentação 125 W AC Config 6 |
| PWR-C6-125WAC / 2 |
Fonte de alimentação 125 W AC Config 6 - Fonte de alimentação secundária |
| PWR-C6-600WAC (=) |
Fonte de alimentação 600 W AC Config 6 |
| PWR-C6-600WAC / 2 |
Fonte de alimentação 600 W AC Config 6 - Fonte de alimentação secundária |
| PWR-C6-1KWAC (=) |
1KW AC Config 6 Fonte de alimentação |
| PWR-C6-1KWAC / 2 |
1KW AC Config 6 - Fonte de alimentação secundária |
| PWR-C5-BLANK = |
Módulo em branco |
| Cabos de alimentação de reposição |
|
| CAB-TA-NA = |
Cabo de alimentação CA para Cisco Catalyst (América do Norte) |
| CAB-TA-AP = |
Cabo de alimentação CA para Cisco Catalyst (Austrália) |
| CAB-TA-AR = |
Cabo de alimentação CA para Cisco Catalyst (Argentina) |
| CAB-TA-SW = |
Cabo de alimentação CA para Cisco Catalyst (Suíça) |
| CAB-TA-UK = |
Cabo de alimentação CA para Cisco Catalyst (Reino Unido) |
| Suprimentos de energia |
|
| Cabos de alimentação de reposição |
|
| CAB-TA-JP = |
Cabo de alimentação CA para Cisco Catalyst (Japão) |
| CAB-TA-250V-JP = |
Cabo de alimentação do Japão 250VAC para Cisco Catalyst (Japão) |
| CAB-TA-125V-JP = |
Cabo de alimentação Japão 125V CA tipo A (Japão - somente 48 portas) |
| CAB-TA-EU = |
Cabo de alimentação CA para Cisco Catalyst (Europa) |
| CAB-TA-IT = |
Cabo de alimentação CA para Cisco Catalyst (Itália) |
| CAB-TA-IN = |
Cabo de alimentação CA para Cisco Catalyst (Índia) |
| CAB-TA-CN = |
Cabo de alimentação CA para Cisco Catalyst (China) |
| CAB-TA-DN = |
Cabo de alimentação CA para Cisco Catalyst (Dinamarca) |
| CAB-TA-IS = |
Cabo de alimentação CA para Cisco Catalyst (Israel) |
| CAB-ACBZ-12A = |
Cabo de alimentação CA para Cisco Catalyst (Brasil), 12A / 125V BR-3-20, plug até 12A |
| CAB-ACBZ-10A = |
AC power cord for Cisco Catalyst (Brazil), 10A/250V BR-3-10 plug up to 10A |
| CAB-C15-CBN |
Cabinet jumper power cord, 250VAC 13A, C14-C15 connectors |
| Rack Mounting Brackets |
|
| ACC-KIT-T1= |
Accessory kit with 19 inch Type 1 rack mount |
| RACK-KIT-T1= |
19, 23, 24 inch and ETSI Type 1 rack mount kit |
| 4PT-KIT-T2= |
4 Point rack mount kit New |
Optics online reference
Cisco Catalyst 9200 Series switches support a wide range of optics. Because the list of supported optics is updated on a regular basis, consult the tables available here for the latest SFP+ and SFP compatibility information: https://www.cisco.com/en/US/products/hw/modules/ps5455/products_device_support_tables_list.html.
Cisco services
Accelerate your journey to intent-based networking
With Cisco Services, you can achieve infrastructure excellence faster with less risk. Our services for Cisco Catalyst 9200 Series switches provide expert guidance to help you successfully plan, deploy, manage, and support your new switches. With unmatched networking expertise, best practices, and innovative tools, Cisco Services can help you reduce overall upgrade, refresh, and migration costs as you introduce new hardware, software, and protocols into the network. With a comprehensive lifecycle of services, Cisco experts will help you minimize disruption and improve operational efficiency to extract maximum value from your Cisco DNA ready infrastructure. Learn more.
Cisco environmental sustainability
Information about Cisco’s environmental sustainability policies and initiatives for our products, solutions, operations, and extended operations or supply chain is provided in the “Environment Sustainability” section of Cisco’s Corporate Social Responsibility (CSR) Report.
Reference links to information about key environmental sustainability topics (mentioned in the “Environment Sustainability” section of the CSR Report) are provided in the following table:
| Sustainability Topic |
Reference |
| Information on product-material-content laws and regulations |
|
| Information on electronic waste laws and regulations, including products, batteries and packaging |
Os links de referência para informações de sustentabilidade ambiental específicas do produto mencionadas nas seções relevantes desta folha de dados são fornecidas na tabela a seguir:
| Tópico Sustentabilidade |
Referência |
| Geral |
|
| Conformidade com o design ecológico (lote ErP da UE, etc.) Certificações ambientais (EPEAT, Energy Star, Etc.) |
Tabela AA. Conformidade do produto Tabela BB. Conformidade do produto ou recursos / benefícios da plataforma |
| Poder |
|
| Potência ociosa, típica ou máxima do produto Recursos de energia ativados por hardware |
Tabela CC. especificações do produto Tabela DD. Recursos / benefícios da plataforma |
| Recursos de energia ativados por software Informações sobre fonte de alimentação Power Calculator |
Tabela EE. Recursos / benefícios da plataforma Tabela FF. especificações do produto Tabela GG. especificações do produto |
| Material |
|
| Unidade de peso Peso do sistema (produto + embalagem) Conteúdo reciclado |
Tabela HH. especificações do produto Quadro II especificações do produto Tabela JJ. especificações do produto |
| Tópico novo ou revisado |
Descrito em |
Encontro |
| Adicionadas imagens corretas para os links de módulo |
Módulos de rede |
21 de fevereiro de 2020 |
| Adicionadas novas informações sobre o C9200 mGig e C9200 32 VN |
28 de janeiro de 2020 |
|
| Novos módulos de rede C9200 adicionados |
28 de janeiro de 2020 |
|
| Mostrar mais histórico> | ||
Comece hoje mesmo o seu projeto de Catalyst 9200 Cisco com a nossa equipe de Serviços Profissionais.
Orientação especializada para criar uma base para obter resultados extraordinários com uma rede que prevê e se adapta, e protege seus negócios.?
Fale com um especialista em Catalyst 9200 da Cisco!
